81.01 VIRZULIS 034 91 00
Compatible with AUDI 100 C3 Sedans (443, 444) , AUDI 100 C4 Sedans (4A2) , AUDI 100 C3 Avant (445, 446) Show more info114.52 EUR
inc. VAT 21%
Out of Stock
No description found
Installation side
at cylinder 3
Installation side
at cylinder 4
Installation side
pie cilindra 5
Installation side
cylinders 3
Installation side
cylinders 4
Installation side
cylinders 5
Cylinder diameter [mm]
81,01
Length [mm]
69,8
Piston head height [mm]
45,75
Screw length [mm]
68,0
Screw diameter [mm]
26,0
Recess depth 1 [mm]
17,2
Recess diameter [mm]
39,6
Valve seat depth 1 [mm]
1,35
machined
with a recess/cutout for the oil nozzle
Surface
coated
Additional article/Additional info 2
with piston ring clamp
Additional article/Additional info 2
without cooling channel
Piston jack height [mm]
9
Product number
81 L 33
Piston clearance [mm]
0,05
Component number
1. R 2.5 IW Mo
Component number
2. M 2.0 IFU
Component number
3. DSF 3.0 Cr
Package height [cm]
12,80
Net weight [g]
814
Package length [cm]
9,5
Package width [cm]
9,50
-
AUDI
-
100 C3 Sedans (443, 444)
- 2.5 TDI (88kW/120PS)
-
100 C4 Sedans (4A2)
- 2.5 TDI (85kW/115PS)
-
100 C3 Avant (445, 446)
- 2.5 TDI (88kW/120PS)
-
100 C4 Avant (4A5)
- 2.5 TDI (85kW/115PS)
-
A6 C4 (4A2)
- 2.5 TDI (103kW/140PS)
- 2.5 TDI (85kW/116PS)
- 2.5 TDI quattro (103kW/140PS)
-
A6 C4 Avant (4A5)
- 2.5 TDI (103kW/140PS)
- 2.5 TDI (85kW/116PS)
- 2.5 TDI quattro (103kW/140PS)
-
100 C3 Sedans (443, 444)
-
VOLVO
-
850 (854)
- 2.5 TDI (103kW/140PS)
-
850 Universālis (855)
- 2.5 TDI (103kW/140PS)
-
S70 (874)
- 2.5 TDI (103kW/140PS)
- 2.5 TDi AWD (103kW/140PS)
-
V70 I (875, 876)
- 2.5 TDI (103kW/140PS)
- 2.5 TDi AWD (103kW/140PS)
-
S80 I (184)
- 2.5 TDI (103kW/140PS)
-
V70 II (285)
- 2.5 TDI (103kW/140PS)
-
850 (854)
VW
