108.00 VIRZULIS MAN D082... Euro2 D70
146.69 EUR
inc. VAT 21%
Out of Stock
No description found
Cylinder diameter [mm]
108,0
Length [mm]
113,0
Piston head height [mm]
73,0
Screw length [mm]
90,0
Screw diameter [mm]
40,0
Recess depth 1 [mm]
16,15
Recess diameter [mm]
70,0
Valve seat depth 1 [mm]
1,7
Valve seat depth 2 [mm]
1,7
machined
with a recess/cutout for the oil nozzle
Surface
coated
Additional article/Additional info 2
with piston ring clamp
Additional article/Additional info 2
without cooling channel
Piston jack height [mm]
20,0
Product number
108 L 56
Piston clearance [mm]
0,12
Component number
1. T 3.0 CrK
Component number
2. M 2.5
Component number
3. DSF 4.0 Cr
Package length [cm]
13,2
Package width [cm]
13,20
Package height [cm]
19,00
Net weight [g]
2172
