BREMŽU DISKS 24.0128-0317.1 09.D417.11
Compatible with TOYOTA C-HR (_X1_) , TOYOTA COROLLA Hečbeka virsbūve (_E21_, _EA1_, _EH1_) , TOYOTA COROLLA Universālis (_E21_) Show more info48.37 EUR
inc. VAT 21%
In stock 4
No description found
Outer diameter [mm]
299,0
Brake disc thickness [mm]
28,0
Minimum thickness [mm]
25,0
Brake disc type
ventilated
Surface
coated
Number of splines
5
Bolt circle-Ø [mm]
114,3
Height [mm]
49,3
Centering diameter [mm]
62,0
Inner diameter [mm]
155,1
Bore diameter [mm]
14,7
Test value
E1 90R-02C0118/0657
-
TOYOTA
-
C-HR (_X1_)
- 1.2 (NGX10_, NGX10R) (85kW/116PS)
- 1.2 4WD (NGX50_, NGX50R) (85kW/116PS)
- 1.8 Hybrid (ZYX10_, ZYX11_, ZYX10R, ZYX11R) (90kW/122PS)
- 2.0 Hybrid (MAXH10) (135kW/184PS)
-
COROLLA Hečbeka virsbūve (_E21_, _EA1_, _EH1_)
- 2.0 Hybrid (MZEH12) (132kW/180PS)
- 2.0 Hybrid (MZEH12) (135kW/184PS)
- 2.0 Hybrid (MZEH19) (144kW/196PS)
-
COROLLA Universālis (_E21_)
- 2.0 Hybrid (MZEH12) (132kW/180PS)
- 2.0 Hybrid (MZEH12) (135kW/184PS)
- 2.0 Hybrid (MZEH19) (144kW/196PS)
-
C-HR VAN (_X1_)
- 1.8 Hybrid (ZYX10, ZYX11) (90kW/122PS)
-
C-HR (_X1_)
TOYOTA
